Test force: 10GF (0.098N), 25GF (0.245N), 50GF (0.49N), 100GF (0.98N), 200GF (1.96N), 300GF (2.94N), 500GF (4.9N), 1KGF (9.8N)
Conform to the standard: GB/T4340.2, GB/T 18449.2, ASTM E92
Measurement resolution: 0.01 μm
Data display output: 8 "touch screen display reading, can store 20 kinds of test results, equipped with U disk, optional built-in printer and RS-232 interface
Conversion scale: Rockwell, Brinell
Hardness test range: 8 ~ 2900 HV/HK,
Test force application method: Automatic (loading, holding, unloading)
Test the magnification of the microscope: 400X(test), 100X (test, observation) (500X\200X optional)
Load holding time of test force: 1-99s
Maximum permissible specimen height: 100mm
Throat depth: 130mm
x-y table: Size: 100*100mm Maximum movement: 25*25mm
Size: 540*260*650mm
Weight: About 50 kg
Power: AC220V + 5%, 50 to 60 hz
Standard Accessory:
Weight shaft: 1
Micrometer Eyepiece (DHV-1000-10X): 1
X-Y table: 1
level: 1
Power cord: 1
Product qualification certificate, warranty card: 1
Printing paper: 1
screwdriver: 2
Weight: 6
Micro hardness block (high block, medium block): Each 1
Universal foot: 4
Fuse (2A): 2
Dust cover: 1
Instructions: 1
Touch pen: 1
Options:
Filament clamping platform: 1
Sheet holder: 1
Flat mouth clamping table: 1
Vickers measurement software: 1 set
