Constellations: GPS L1, L2, L5; Galileo E1, E5a/b, E6; GLONASS L1, L2, L3; BeiDou B1, B2, B3; QZSS L1, L2, L5; NavIC L5 & S-Band; In Band SBAS
Further signals in the upper and lower L band can be configured with the internal webserver. Bespoke requirements like Iridium & Sirius XM radio frequencies are available on request.
Nominal Output Signal Level: -73dBm/MHz @ 0dB
Variable attenuator provides between +20 dB and –69 dB of adjustment during replay
RF Channels : 3
RF Channel 1 Centre Frequency: Selectable
RF Channel 2 Centre Frequency: Selectable
RF Channel 3 Centre Frequency: Selectable
Number of Satellites Observed: All in view
Sampling Frequency: 10.23MHz, 30.69MHz, 58MHz
Bandwidth: 10MHz, 30MHz, 56MHz
Quantisation: 1, 2 or 3 bit (I & Q)
Data Format: I & Q
Additional Logging: 2x CAN channels, 4x Digital channels
Removable Battery Pack: Yes
Media Storage Included: 1TB SSD & 8GB SD card (SD card for firmware upgrade only)
Active Antenna Voltage Supply: 2.8 – 4.6 v
Reference Oscillator:
TCXO
Temperature Stability +/- 0.05 ppm
Frequency Stability +/- 1 ppm over first year
OCXO
Temperature Stability +/- 0.05 ppm
Frequency Stability +/- 0.3 ppm over first year
Operating Voltage: 8V to 30 VDC
Size: 167 mm x 128 mm x 46 mm
Weight: 1.2 kg
