Inner Size (D*W*H): 800*700*900mm
Capacity: 11KW
Chamber Volume: 576L
Performance
Temp range: -40℃～+150℃, -70℃～+150℃
Temp constancy: ±0.5％
Temp deviation: ≥100℃, ±3.0℃ (at constant pressure with empty load); ＜100℃, ±2.0℃ (at constant pressure with empty load)
Cooling rate: 0.7℃～1.0℃/min (Overall average)
Pressure range: Constant pressure ～1kPa
Pressure constancy: When ≥40kPa, ±2kPa, 4kPa～40pKa ±0.5kPa, when≤4kPa, ±0.1kPa
Depressurization rate: Constant pressure～1kPa≤30mins (Normal temp)
Pressure recovery rate: 10kPa/Min (adjustable）
Material
Exterior material: Cold-rolled steel sheet (Rust proof&Plastic Spray treated)/Stainless Steel plate
Interior material: Stainless steel (SUS304)
Pressurized parts: High quality steel plate (Rustproof & Plastic spray treated)
Insulation material: High-quality glass wool
Cooling System
Compressor: Semi-Hermetic Compressor
Cooling Mode: Water-cooled
Temp regulating method: Balanced Temperature & Humidity Control System (BTHC）
Pump: Rotary vane type vacuum pump
Heater: Iron-chrome wire heater
Sight window: Circular viewing glass incorporating heat generator
Temp Sensor: Pt-100
Controller: Touch Screen Controller
Safety Devices: Over pressure, over heat and over current protection for compressor, over temp. protection, over load protection for blower, Hydraulic and Water lack Protection, leakage protection, phase-lack protection, Pump failure alarm
Standard Accessory: Sight window, Cable Port (1 located on the left side), Baffle, Baffle frame*2
Power: AC380V/50Hz, 3Phase 5 wires+ Ground Wire.
