Rated Range:
Voltage: 0~1000V
Current: 0~35A
Power: 0~15kW
Load Regulation:
Voltage: ≤0.02%+300mV
Current: ≤0.05%+20mA
Line Regulation:
Voltage: ≤0.01%+150mV
Current: ≤0.05%+20mA
Setting Resolution:
Voltage: 0.1V
Current: 0.01A
Display Resolution:
Voltage: 0.001V
Current: 0.001A
Setting Precision:
Voltage: 0.05%FS+5dgt
Current: 0.2%FS+5dgt
Display Precision:
Voltage: 0.05%FS+5dgt
Current: 0.2%FS+5dgt
Ripple:
Voltage: ≤400mV (rms) & 2.4V (p-p)
Current: ≤26mA (rms)
Temperature Coefficient of Constant Voltage & Current: Voltage: 0.03%/℃
Rise Slew Rate (no load): Voltage: 0.001V/ms~10V/ms
Rise Slew Rate (CR full load): Voltage: 0.001V/ms~10V/ms
Fall Time (no load): Voltage: ≤2s
Dynamic Response Time: ≤1.5ms
AC Input:
Voltage: 342VAC~462VAC
Frequency: 45Hz~65Hz
Efficiency: 95%
Power Factor: 0.99
Max. Input Current: 26A
Max. Apparent Power: 17kVA
Storage Temperature: -10~70℃
Protection: OVP/OCP/OPP/OTP etc.
Communication Interface: RS485/LAN/USB/CAN
Other Interface: Remote sampling interface/RJ-45
Withstand Voltage: 2000Vdc
Ambient Temperature: 0~40℃
Dimensions: 736mm (D) × 445mm (W) × 132.5mm (H)
Weight: 46kg
