KEM HM 030 TRI Turbine Flow Meters (35 - 400 L/min) | EMIN.CO.ID

Turbine Flow Meters
KEM HM 030 TRI Turbine Flow Meters (35 - 400 L/min)

Stay Updated with Offers

Get exclusive volume discounts, bulk pricing updates, and new product alerts delivered directly to your inbox.

By subscribing, you agree to our Terms of Service and Privacy Policy.

Quick Support

Direct access to our certified experts

Product image

KEM HM 030 TRI Turbine Flow Meters (35 - 400 L/min)

ManufacturerKEM(View more products from this manufacturer)

ModelHM 030 TRI

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Technical Data – Sizes

HM types: HM 030 TRI

Measuring Range (l/min): 35 - 400 L/min

K-Factor (pulses/l): 130 (pulses/l)

Max. Pressure: 10 [145] (bar/psi)

Max. Frequency (Hz): 1,850 Hz

Weight: 3.2 kg

Technical Data – General

Measuring Accuracy: ±1%

Repeatability: ±0.05 % (under the same condition)

Linearity: ±1 % of actual flow

Viscosity Range: 1 mm2/s

Materials

Housing: as per DIN 1.4404 [AISI 316L]

Wheels: as per DIN 1.4460 [AISI 329]

Bearing: PTFE

Inner seal: FKM

Medium Temperature: -40 °C up to +150 °C [-40 °F up to +302 °F]

Dimensions: See dimensional drawing

See datasheet for choosing suitable configurations!

Dimensional Drawing

Datasheet

Manual
