Measuring Range: 0~1250 μm
Measurement accuracy: (±3%H+1μm)
Display accuracy: 1 μm
Min. measurement area: 10μm * 10μm
Min. Base thickness:
Fe: 0.2mm
NFe: 0.05mm
Minimum Curvature:
Convex curve radius: 5mm
Concave curve radius: 25mm
Display: LCD
Power: Four 7th battery
Weight: 82g without battery
Working temperature: -10℃ ~ +60℃
Dimension: 112*69*28mm (Host)
Datasheet
Main features:
Ruby wear-resisting prole: The wear resistance of probe contact point affects the accuracy of measurement directly. Ordinary metal contact probe, after its surface wear will bring great error .
Probe and the host hold in one piece .
One button set Zero, calibration, measuring and all operations .
Widely used in manufacturing, metal processing industry, chemical industry, commodities inspection, and other test areas.
Particularly suited to engineering field measurement.
Durable, widely used, one-handed operation .
