Performance Data Temperature
Temperature range 5 °C above ambient temperature to [°C]: 300
Temperature variation at 150 °C [± K]: 2.5
Temperature fluctuation at 150 °C [± K]: 0.3
Heating-up time to 150 °C [min]: 25
Recovery time after 30 seconds door open at 150 °C [min]: 6
Air change data
Air change (approx.) at 150 °C [x/h]: 64
Electrical data
Rated Voltage [V]: 230
Power frequency [Hz]: 50 / 60
Nominal power [kW]: 0.8
Unit fuse [A]: 10
Phase (Nominal voltage) [ph]: 1~
Outer dimensions
Width net [mm]: 435
Height net [mm]: 495
Depth net [mm]: 520
Wall clearance back [mm]: 160
Wall clearance sidewise [mm]: 100
Doors
Unit doors: 1
Internal Dimensions
Width [mm]: 222
Height [mm]: 330
Depth [mm]: 300
Further Dimension
Interior volume [L]: 20
Net weight of the unit (empty) [kg]: 27
Permitted load [kg]: 25
Load per rack [kg]: 12
Environment-specific data
Energy consumption at 150 °C [Wh/h]: 300
Fixtures
Number of shelves (std./max.): 2 / 4
