Performance Data Temperature
Temperature range 5 °C above ambient temperature to [°C]: 300
Temperature variation at 150 °C [± K]: 3
Temperature fluctuation at 150 °C [± K]: 0.5
Heating-up time to 150 °C [min] 71
Recovery time after 30 seconds door open at 150 °C [min]: 31
Electrical data
Rated Voltage [V]: 400
Power frequency [Hz]: 50 / 60
Nominal power [kW]: 3.4
Unit fuse [A]: 3 x 16
Phase (Nominal voltage) [ph]: 3 ~
Outer dimensions
Width net [mm]: 1235
Height net [mm]: 1025
Depth net [mm]: 765
Wall clearance back [mm]: 160
Wall clearance sidewise [mm]: 100
Doors
Unit doors: 2
Internal Dimensions
Width [mm]: 1000
Height [mm]: 800
Depth [mm]: 520
Further Dimension
Interior volume [L]: 400
Net weight of the unit (empty) [kg]: 125
Permitted load [kg]: 90
Load per rack [kg]: 35
Environment-specific data
Energy consumption at 150 °C [Wh/h]: 672
Fixtures
Number of shelves (std./max.): 2 / 10
