Dimensions and volumes:
Dimensions (W × L × H): 20.9 x 26.2 x 49.6 in.
Internal usable expansion volume: 7.5 l
Minimal process volume: 7.5 l
Active heat exchanger volume: 3.5 l
Weight: 463 lbs
Pump connections: M30x1.5 male
Cooling Water Connection: G¾ in.
Temperature values:
Working temperature range: -50 ... +250 °C
Temperature stability: ±0.05 ... ±0.1 °C
Setting the resolution of the temperature display: 0.01 °C
Temperature display resolution: 0.01 °C
Ambient temperature: +5 ... +40 °C
Performance values: 230V/3PPE/50Hz (Plug 63A CEE)
Heating capacity: 12 kW
Cooling capacity: 7 kW
Refrigerant: R452A
Global Warming Potential: 2140
Filling weight: 1100 g
Carbon dioxide equivalent: 2.354 t
Pump capacity flow pressure: 0 ... 80 l/min
Circulation capacity pressure: 1.5 ... 43.5 psi
Viscosity max.: 50 cSt
Power consumption: 39 A
Cooling:
Cooling of compressor: 1-stage Water
Cooling water pressure max.: 87 psi
Recommended cooling water properties
Cooling water temperature range: 35 °C
Cooling water difference pressure: 7.3 psi
Cooling water consumption: 8 ... 12 l/min
Electronics:
Interfaces: Alarm output / Ethernet / Modbus / Profibus optional / REG/EPROG optional / RS232 / RS485 optional / SD memory card / Standby-Input optional / USB
External pt100 sensor connection: integrated
2nd external Pt100 sensor connection: accessory
Integrated programmer: 8x60 steps
Temperature control: ICC
Absolute temperature calibration: 3 Point Calibration
Temperature display: 5.7" TFT Touchscreen
Temperature setting: Touchscreen
