Dimensions and volumes:
Dimensions (W × L × H): 12.6 x 17.7 x 35.8 in.
Filling volume: 24 l
Usable immersion depth: 12.2 in.
Weight: 112.4 lbs
Temperature values:
Working temperature range: -30 ... +200 °C
Temperature stability: ±0.005 °C
Temperature display resolution: 0.01 °C
Ambient temperature: +5 ... +40 °C
Performance values: 230V/50Hz (Schuko Plug - CEE 7/4 Plug Type F)
Heating capacity: 2 kW
Cooling capacity: 0.46 kW
Refrigerant: R134a
Global Warming Potential: 1430
Filling weight: 200 g
Carbon dioxide equivalent: 0.286 t
Pump capacity flow pressure: 22 ... 26 l/min
Circulation capacity pressure: 5.8 ... 10.2 psi
Maximum suction: 2.9 ... 5.8 psi
Viscosity max.: 70 cSt
Power consumption: 14 A
Bath:
Bath tank: Stainless steel
Bath cover: integrated
Usable bath opening (W x L / D): 4.7 x 0 / 12.2 in.
Cooling:
Cooling coil: not available
Cooling of compressor: 1-stage Air
Electronics:
Interfaces: Profibus optional
External pt100 sensor connection: integrated
Integrated programmer: 6x60 steps
Temperature control: ICC
Absolute temperature calibration: 3 Point Calibration
Temperature display: VFD
Temperature setting: Keypad
