Temperature values
Setting the resolution of the temperature display °C: 0.01
Working temperature range °C: -40~+100
Temperature stability °C: ±0.01
Ambient temperature °C: +5~+40
Temperature display resolution °C: 0.01
Cooling
Cooling of compressor: 1-stage Air
Bath
Bath tank: Stainless steel
Bath cover: integrated
Usable bath opening cm (W x L / D): 35 x 40 / 30
Voltage: 200-230V/50-60Hz (UK Plug Type BS1363A) (R1270)
Electronics
Interfaces Alarm output optional, REG/EPROG optional, RS232 optional, Standby-Input optional, USB
External pt100 sensor connection: integrated
Integrated programmer: 8x60 steps
Temperature control: PID3
Other
Classification: Classification III (FL)
IP Code: IP 21
Pump function: Pressure Pump
Pump type: Immersion Pump
User Interface Language: Chinese, English, French, German, Italian, Japanese, Korean, Portuguese, Russian, Spanish
Dimensions and volumes
Weight kg: 68
Barbed fittings inner diameter mm: 8/12 mm
Total dimensions cm (W × L × H): 45 x 64 x 95
Filling volume l: 48~56
Pump connections: M16x1 male
Absolute temperature calibration: 3 Point Calibration
Temperature display: 3.5" TFT Display
Temperature setting: Shaft Encoder
Electronic Timer h:min: 00:00 ... 99:59
