Dimensions and volumes:
Dimensions (W × L × H): 17.7 x 25.2 x 37.4 in.
Filling volume: 48 ... 56 l
Weight: 162.5 lbs
Pump connections: M16x1 male
Barbed fittings inner diameter: 8/12 mm
Temperature values:
Working temperature range: -38 ... +100 °C
Temperature stability: ±0.01 °C
Setting the resolution of the temperature display: 0.01 °C
Temperature display resolution: 0.01 °C
Ambient temperature: +5 ... +40 °C
Performance values: 230V/50Hz (Schuko Plug - CEE 7/4 Plug Type F)
Heating capacity: 2 kW
Cooling capacity: 1 kW
Refrigerant: R449A
Global Warming Potential: 1397
Filling weight: 170 g
Carbon dioxide equivalent: 0.23749 t
Pump capacity flow pressure: 8 ... 27 l/min
Circulation capacity pressure: 1.5 ... 10.2 psi
Viscosity max.: 50 cSt
Power consumption: 16 A
Bath:
Bath tank: Stainless steel
Bath cover: integrated
Usable bath opening (W x L / D): 13.8 x 16.1 / 11.8 in.
Cooling:
Cooling of compressor: 1-stage Air
Electronics:
Interfaces: Alarm output optional / REG/EPROG optional / RS232 optional / Standby-Input optional / USB
External pt100 sensor connection: integrated
Integrated programmer: 8x60 steps
Temperature control: PID3
Absolute temperature calibration: 3 Point Calibration
Temperature display: 3.5" TFT Display
Temperature setting: Shaft Encoder
Electronic Timer (h:min): 00:00 ... 99:59
