Application
Solid-state laser pumping
Medical application
Material processing
Specification
Optical Parameters
Output Power: min 80W
Center Wavelength (nm): min 877.6; typical 878.6; max 879.6
Spectral Width(FWHM): typical 0.5 nm
Back Reflection Isolation Range (nm): min 1040; typical 1060; max 1200
Electrical Parameters
Conversion Efficiency (%): typical 45
Threshold Current (A): typical 1.8
Operating Current (A): typical 9.5; max 10
Operating Voltage (V): typical 17; max 20
Slope Efficiency (W/A): typical 7
Fiber Parameters
Core Diameter (μm): typical 400
Numerical Aperture (NA): typical 0.22
Fiber Length (m): typical 1.5
Fiber Connector: typical SMA905
Fiber Bend Radius (mm): min 80
Thermal Parameters
Package Operating Temperature (℃): min 20; max 35
Storage Temperature (℃): min -20; max 85
Wavelength Temperature Coefficient (nm/℃): typical 0.3
Lead Soldering Temperature (℃): typical 260
Lead Soldering Time (s): typical 10
JPT has different kinds of semiconductor laser components and high-power laser modules. Semiconductor laser can be widely used in pump source, industrial processing, mechanical vision, medical and many other fields. Based on the mature coupling technology solution, thermal control and packaging process, the product has the advantages of high power, high beam quality, high stability, etc., and the product wavelength covers 400nm~1000nm, which meets the special requirements of power, brightness, wavelength control, spot uniformity and so on.
