Max Weight of Workpiece (kg): 5
Max Diameter of Workpiece (mm): 40-120
Rotor Stack Thickness (mm): 30-120
Journal Diameter (mm): φ8-34
Balancing Speed (r/min): ≤2500
Balancing Motor Power (kw): 0.4 KW Servo Motor
Min Achievable Residual Unbalance Amount (g.mm/kg): ≤0.3
Testing Time (second): 45999
Reduction Rate of Unbalance: ≥90%
Working Pressure (MPa): 0.4-0.6
Operating Voltage (V): AC: 380V external
Weight-Removing Method: Drilling
Drilling Power (kw): 0.75
Balancing Machine Type: Soft Bearing Measuring Bracket
Machine Power (kw): 6.75
Average Machine Consumption(l/min): 60
Protection: Phase sequence protection, overload protection, pressure monitoring
