Weight:5-50kg
Measuring System:Shanghai Jianping
Bearing Shaft Diameter:15-75mm
Driven Measuring Motor:1.5kw Panasonic Servo Motor
Lamination Thickness:80-450mm
Drilling Engaging Motor:0.75kw Panasonic Servo Motor
Lamination Diameter:80-300mm
Drilling Spindle Motor:0.75kw
Deweight Diameter:60-280mm Cylinder:SMC
Drilling Diameter:max 16mm Drilling Track:ShangYin
Distance between Drilling Cutter and plane:10-150mm
Main Driven Motor:Taiwan Hankun
Min Residual Unbalance Rate:<0.5g.mm/kg
Vacuum Cleaner:Suzhou Deico
Unbalance Reduction Rate by One Time >95%
Special rotor need to be confirmed with engineer
Processing period:150s (it will change accoring to weight.material.dimension)
