Mass of Workpiece(kg): 150(clamp included)
Max Height of Workpiece (mm): 200
Max Diameter of Workpiece (mm): 200-600
Balancing Speed（r/min): 800
Motor Power（kw）: 7.5
Min Achievable Residual Unbalance Amount (g.mm/kg): 3
Drilling Speed（r/min）: 1500 frequency conversion
Cutting Spindle Motor Power(kw): 1.5
Max Allowed Correct Times: 2
Machine Weight(ton): 2
Dimensions(mm): 950*1700*2000
Pressure(Mpa): 0.4-0.6
Processing Period(s): 15-20
Total Power（kw）: 15
Rotor thickness (mm): 200
Operating Voltage（v）: AC:380External
Drilling Method: Standard drill
Balancing Machine Type: Hard bearig bracket
Average Gas Consumption : 6 L/min
Unbalance Reduction Rate: ≥95%
Protection: Phase sequence protection. Overload protection. Pressure detection
