Size
Internal Dimension WxHxD (mm): 1000x1000x800
External Dimension WxHxD (mm): 1400x2080x2050
Volume (L): 800L
Pressure
Pressure range: Normal pressure~0.5Kpa ( 500pa）
Pressure error:
+ Ordinary pressure~40kpa≦±2kpa;
+ 40kPa~4kPa≦±5kPa;
+ 4kPA~1kPa≦±0.1kpa
Depressurization time:
+ From site level to 15250m in 10minutes
+ From site level to 22860m in 20minutes
+ From site level to 30500m in 30minutes
Rapid decompression time: 75.2kPa~18.8kPa≦15s (Optional)
Explosive decompression time: 75.2kPa~18.8kPa≦0.1s (Optional)
Temperature
Temperature range
+ Low temperature range: -70℃
+ High temperature range: 150℃(180℃ is Optional)
Temperature fluctuation: ±0.5℃
Temperature Rising/Falling Speed Rate:
+ Temperature rising approx:0.1~ 2.0℃/min;
+ Temperature falling approx:0.3-1.0℃/min
Temperature uniformity: ±1.5℃(-40.0℃∽100.0℃); ±2.0℃(100.1℃~180.0℃or-40.0℃∽-70.0℃)
Humidity
Humidity range: 20%RH~98%RH(work under atmos pheric humidity）; 10%R.H ~98%R.H (Optional)
Humidity fluctuation: ±2.0%RH
Humidity uniformity: ≦±3.0%RH(humidity >75%R.H); ≦±5.0%RH(humidity ≦75%R.H)
Power: AC380V 3phase 5lines 50/60Hz
Aprroximate weight(kg): 1200
