Sensitivity 5.1mV/(m/s2) (50mV/G) ±10%
Frequency range (±3dB) 5 to 8,000Hz
Maximum measuring acceleration 343m/s2 (35G)
Shock survivability 9,800m/s2 (1,000G) Peak
Mounted resonance frequency 12kHz min.
Operating temperature range -10 to +150°C
Preserve temperature range -15 to +155°C
Weight 138g
Case material SUS303
Cable φ3 Coaxial cable (fluoropolymer-coated)
Mounting JIS M10, Length 7mm
Amplifier Preamplifier built-in
Excitation voltage +12 to +25VDC
Constant current excitation +0.88 to +5.1mA
Output bias voltage +5.13 to +8.90VDC
Electrical isolation Case isolated
Protection against ingress of water IPX7
