Jeiotech SIF-5000 Incubated Shakers (Chamber Models) | EMIN.CO.ID

Jeiotech SIF-5000 Incubated Shakers (Chamber Models)

Name: Jeiotech SIF-5000 Incubated Shakers (Chamber Models)
Brand: JEIOtech

ManufacturerJEIOtech(View more products from this manufacturer)

ModelSIF-5000

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Model: SIF-5000
Manufacturers: Jeiotech
Origin: Korea
warranty: 12 months

Temperature    Range (℃ / ℉)    Amb. 5~80 /
                                Fluctuation at 37℃ (±℃ / ℉)0.2 / 0.36
                                Variation at 37℃ (±℃ / ℉)    0.15 / 0.27
Shaking System Speed 10 to 300 (Stackable Top :10 to 250)
Dimension (W×D×H) Internal (mm / inch) 600×500×500 /
                                 Overall (mm / inch)    735×742×1010 /
                                 Net Weight (kg / lbs)    100
Electrical Requirements (230V, 50 / 60Hz)    4A
Cat. No.    AAH22041K

Inside of SIF Models

Shaking Features

Dual shaking modes: orbital or reciprocating mode selectable.
Speed range: 10 to 300 rpm. (10 to 250rpm for the top unit of a stack)
Programmable shaking control.
- Timer range: 10 sec to 999 hr 59 min 59 sec.
- Forward & Backward, Pause: 10 sec to 59 min 59 sec.
Selectable orbit diameter or stroke length.
- SIF-5000 and SIF-5000R: 13 and 19mm.
- SIF-6000 and SIF-6000R: 19 and 25mm.

Operating Features

Temperature control:
+5°C above ambient to 80°C. (for SIF-5000 and SIF-6000)
-20°C below ambient to 80°C. (for SIF-5000R and SIF-6000R)
Microprocessor PID control.
Simple calibration and auto-tuning functions.
Timer with Delayed ON/OFF function: 1 min to 99 hr 59 min.
High temperature limit setting and open door alarm.
Convenient preset function for 3 most commonly used temperature settings.
Up to 9 temperature steps and maximum 200 cycles of repetition programmable for each profile.
Adjustable 3-step fan speed with defrosting time and period control.
Intuitive control panel with LED display and touch-sensitive keypad.
RS-232 interface.

Constructional Features

Stackable up to 2 units.
Maintenance-free and durable BLDC motor.
High-velocity fan ensuring uniform temperature distribution and rapid thermal recovery.
Convenient sample monitoring thanks to the transparent front window and the built-in lamp minimizing the need to open the door.
Environment-friendly CFC-free refrigerant. (for SIF-5000R and SIF-6000R)
Built-in casters for easy transport.
Lockable door for added safety.
Built-in electrical outlet with a safety cover inside the chamber.

Model		SIF-5000		SIF-5000R		SIF-6000		SIF-6000R
Temperature ¹⁾	Range (℃ / ℉)	Amb.+5 to 80 [Amb.+9 to 176] for SIF -5000, 6000 Amb.-20 to 80 [Amb. -36 to 176] for SIF -5000R, 6000R
	Fluctuation at 37℃ (±℃ / ℉)	0.1 / 0.18
	Variation at 37℃ (±℃ / ℉)	1 / 1.8
	Refrigerator (Hp)	-		1/8Hp, HBP		-		1/6Hp, HBP
Shaking System	Motion Type	Orbital or Reciprocating motion (Default : Orbital motion)
	Speed Range (RPM)	10 to 300 (Stackable Top :10 to 250)
	Timer	Run time(10sec ~ 999hr 59min 59sec) Pause, Forward, Backward(10sec ~ 59min 59sec)
	Amplitude Size (mm / inch, dia.)	19, 25 / 0.75, 1 Available - Standard 19 / 0.75				25, 38 / 1, 1.5 Available - Standard 25 / 1
	Recip Stroke Length (mm / inch)	19, 25 / 0.75, 1 Available - Standard 19 / 0.75				25, 38 / 1, 1.5 Available - Standard 25 / 1
Dimension	Volume (L / cu ft)	80 / 2.8				150 / 5.3
	Platform (W×D, mm / inch)	350×350 / 13.8x13.8				450×450 / 17.7×17.7
	Interior (W×D×H, mm / inch)	440×440×418 / 17.3×17.3×16.5				540×540×518 / 21.3×21.3×20.4
	Exterior (W×D×H, mm / inch)	570×815×900 / 22.4×32.1×35.4				670×895×980 / 26.4×35.2×38.6
	Shelves (Standard / Max)	2 / 8				2 / 11
	Net Weight (kg / Ibs)	120 / 264.6		130 / 286.6		140 / 308.6		150 / 330.7
Electrical Requirements (230V)		60Hz, 4A	50Hz, 4A	60Hz, 7.2A	50Hz, 7.2A	60Hz, 5.4A	50Hz, 5.4A	60Hz, 7.3A	50Hz, 7.3A
Cat. No.		AAH27021K	AAH27022K	AAH27121K	AAH27122K	AAH27011K	AAH27012K	AAH27111K	AAH27112K
Electrical Requirements (120V)		50/60Hz, 11.1A		60Hz, 12.9A		50/60Hz, 11.2A		60Hz, 13.1A
Cat. No.		AAH27026U		AAH27123U		AAH27016U		AAH27113U

※ Permissible environmental conditions: temperature (5℃ to 40℃) and relative humidity (up to 80%).
※ All specifications are under ambient temperature 20℃(with refrigerator) / 25℃(without refrigerator), no load.1) Technical data according to DIN 12880.
