Peak power: 150 W
Selectable temperature: 90 to 450 ºC / 190 to 840 ºF
Solder wire diameter: 1.0 mm / 0.04 in with GALE10V already assembled
Max. wire length: 250 mm / 9.84 in
Min. wire length: 0.5 mm / 0.02 in
Temperature accuracy: ±3%
ESD safe: Meet ANSI/ESD S20.20-2021
Tip-to-ground resistance: <2 ohms
Tip-to-ground voltage: <2 mV RMS
USB-A:
Firmware update
Graphics and profiles
USB-B: PC communications
FAE / Robot connector: Remote control or FAE Fume Extractor connection
COMPATIBLE SOLDER REEL
Weight: up to 2 kg / 4.4 Ib
Diameter: max. 100 mm / 3.94 in
Height: max. 100 mm / 3.94 in
Reel stand axis: Ø 10 mm / Ø 0.4 in
WEIGHT AND DIMENSIONS
Control Unit:
235 x 170 x 112 mm / 7.83 kg.
9.25 x 6.69 x 4.41 in / 17.25 lb.
Package:
545 x 345 x 275 mm / 8.46 kg.
21.46 x 13.58 x 10.83 in / 18.65 lb.
