Width: 14 mm
Height: 5.1 mm
Length: 16.05 mm
Fall Time: 32 ns
Rise Time: 33 ns
Technology: Si
Unit Weight: 4.500 g
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 300 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 21 ns
Typical Turn-Off Delay Time: 62 ns
Id - Continuous Drain Current: 12 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 1.05 Ohms
Vds - Drain-Source Breakdown Voltage: 1 kV
