Fall Time: 15 ns
Rise Time: 18 ns
Technology: Si
Unit Weight: 6.500 g
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 178 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 170 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 23 ns
Typical Turn-Off Delay Time: 33 ns
Id - Continuous Drain Current: 120 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 5.8 mOhms
Vds - Drain-Source Breakdown Voltage: 75 V
Vgs th - Gate-Source Threshold Voltage: 2 V
