Width: 5.029 mm (0.198 in)
Height: 20.879 mm (0.822 in)
Length: 19.914 mm (0.784 in)
Output Type: SCR
Unit Weight: 5.684 g
Contact Form: SPST (1 Form A)
Input Current: 50 mA
Mounting Style: PCB Mount
Termination Style: Solder Pin
Relay Contact Form: 1 Form A (SPST-NO)
Load Current Rating: 5 A
Load Voltage Rating: 20 VAC to 240 VAC
Control Voltage Range: 900 mVDC to 1.4 VDC
Pd - Power Dissipation: 3.5 W
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Input to Output Isolation Method: Optical Isolation
