Input/Output Frequency Range: 400 to 7300 MHz
IF Bandwidth: 180 MHz
Input Power Range: +30 dBm peak (+25 dBm average)
Output Power Range (CW): -8 dBm to -130 dBm
Output Power Range (CW, Broadcast): -23 dBm to -130 dBm
Input Power Accuracy:
Specification: ±0.5 dB (+25 dBm to -40 dBm)
Typical: ±0.3 dB (+25 dBm to -40 dBm)
Output Power Accuracy:
Specification: ±0.75 dB (-8 dBm to -90 dBm); ±1.50 dB (-90 dBm to -130 dBm)
Typical: ±0.5 dB (-8 dBm to -90 dBm); ±1.0 dB (-90 dBm to -130 dBm)
Output Power Accuracy (Broadcast):
Specification: ±1.0 dB (-23 dBm to -90 dBm); ±1.50 dB (-90 dBm to -130 dBm)
Typical: ±0.75 dB (-23 dBm to -90 dBm); ±1.0 dB (-90 dBm to -130 dBm)
EVM:
Residual Loopback EVM, Full Packet Channel Estimation, Typical: Power In/Out: -20 dBm; Averaged Over: 20 packets
Measured at 6825 MHz
802.11ax Waveform, 160 MHz, MCS 11
≤ - 47 dB
Input/Output Return Loss: >13 dB
