Basic
Sensor: 4K
Image Sensor: CMOS
Shutter: Global
Resolution: 4096 × 2
Line Rate: 28 kHz(After compression the line frequency is 59.9k）
Bit Depth: 12
Mono/Color: Mono
Pixel Size: 7 μm × 7 μm
S/N Ratio: >39dB
Dynamic Range: 66dB
Image Format: Mono8/10/12/10Packed/12Packed
ROI: Support
X Flip: Support
Gain: 1~32
Gamma: From 0 to 4，support LUT
Exposure Time: 8μs~100ms
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
FPN: Support
TDI Stages: single_line，2TDI
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 64MB image cache，64MB data cache
Port
Port: GigE
GPIO Interface: 12-pin Hirose interface for external power supply and external triggering; 2 differential/single-ended inputs, 1 differential configurable input or output, 1 high-speed optocoupler single-ended input, 1 GPIO configurable input or output
Lens Mount: M42 x 1
Power
Power Supply: DC 12~24V power supply via 12-pin Hirose connector
Power Consumption: ≈4.5W
Structure
Product Dimensions: 62 mm × 62 mm × 44 mm (Not including rear case connector)
Net Weight: 245 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
