Basic
Sensor: Customized
Image Sensor: 29.9 mm × 22.4 mm CMOS
Shutter: Global
Resolution: 7008 × 7000
Frame Rate: 17.4 fps
Bit Depth: 12 bit
Mono/Color: Mono
Pixel Size: 3.2 μm × 3.2 μm
Pixel: 50 MP
S/N Ratio: 40 dB
WDR: 66 dB
Image Format: Mono8
Decimation: Support
ROI: Support
X Flip: Support
Y Flip: Support
Gain: 1 ~ 32
Gamma: 0 ~ 4，support LUT
Exposure Time: 16 μs ~ 15 s
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 1 GB
Port
Port: 10GigE
GPIO Interface: 3× Opto-isolated input, 3× Opto-isolated output, 1× RS232
Lens Mount: M58 × 0.75
Power
Power Supply: DC 24V power supply via 12-pin Hirose interface
Power Consumption: 24 V ≈ 20.16 W
Structure
Product Dimensions: 72 mm × 72 mm × 80.5 mm (not including rear case connector)
Net Weight: 600 g
Environment
Storage Temperature: -30℃ ~ 80℃
Operating Temperature: 0℃ ~ 50℃
