Basic
Sensor: IMX287
Image Sensor: 1/2.9" CMOS
Shutter: Global
Resolution: 720 × 540
Frame Rate: 349 fps
Bit Depth: 10
Mono/Color: Màu
Pixel Size: 6.9 μm × 6.9 μm
Pixel: 0.4MP
S/N Ratio: >38dB
WDR: >70dB
Image Format: Mono8/10
ROI: Support
X Flip: Support
Y Flip: Support
Gain: 1~32
Exposure Time: 16μS~1S
Trigger Mode: Software Trigger/Acquisition Board Hardware Trigger/Free Run Mode
User Setting: Support two sets of user-defined configurations
Pixel Clock: 32M/48M/64M/80M
Port
Port: CameraLink
Lens Mount: C-mount
Power
Power Supply: PoCL
Power Consumption: ≈2.38W
Structure
Product Dimensions: 29mm*29mm*43.8mm(not including lens mount and rear case connector)
Net Weight: 80 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
