Max. test force: 300kN
Accuracy class: 0.5 class
Test force measurement accuracy: ±0.5% of indicated value
Range of test force: 0.2% - 100%FS
Resolution of test force: 1/500000FS
Crossbeam displacement accuracy: ±0.5% of indicated value
Crossbeam displacement resolution: 0.025μm
Range of speed adjustment: 0.001-500mm/min
Accuracy of crossbeam speed:
±1% of the set value, (speed<0.5mm/min)
±0.2% of the set value, (speed≥0.5mm/min)
Range of force control speed: 0.005~5%FS/S
Accuracy of constant load force:
±2% of the set value, (speed<0.05%FS/s)
±0.5% of the set value, (speed≥0.05%FS/s)
Compression fixture: Ø150mm
Wedge tension fixture
flat jaw: 0~30mm
V-jaw: Ø8-Ø36mm
Effective test width: 600mm
Vertical test space: 1000mm
Effective compression height: 600mm
Power supply: AC 380V, 50Hz, 0.4kW-kW, 3Ø
Dimension: 1070x920x2550mm
Weight: 1500kg
