Light source: Semiconductor laser
Resolution: ≤10% (GB/T18854, ISO11171)
Coincidence error limit: Repeatable 12000~40000 particle/ml
Sampling volume: 0.2~6000ml, interval 0.1ml
Sampling error: <0.5%
Sampling rate: 5~80ml/min
Sample temperature: -30~80°C
Working temperature: -20~60°C
Storage temperature: -30~80°C
Particle size range: 1~100µm (ACFTD standard) or 4~70µm(c) (ISO MTD standard)
Counting accuracy: <5%
Sensitivity: 0.8µm (ISO4402) or 3µm(c)
Sample viscosity: ≤650cSt
Test channel: 8~64 channels selectable (default 64 channels)
Pressure range: -0.08Mpa~0.8Mpa
Temperature sensor: Optional, measurement range: 1~100°C, accuracy: 1°C
Water activity sensor: Optional, measurement range: 0~1aw, accuracy: 0.03aw
Water content sensor: Optional, measurement range: 1~360ppm, accuracy: 1ppm
Interface type: RS232, RE485, and USB
Data store: 1000 sets of data can be stored, and support U disk storage
Weight: 23kg
Dimension (W×H×D): 340×410×650mm
Power supply: AC 110-240V, 50~60Hz, 70W
