Measuring range (Fe) 0-1500 µm
Accuracy : ±(2%L+2) µm
Resolution : : 0.1µm (<100µm) , 1µm (≥1000µm)
Repeatability : 1µm ( 0-100µm) .±1%Lµm (≥100µm)
Measuring mode : continuous or single
Calibration mode : Zero ang one point, two points calibration
Minimum substrate thickness : magnetic induction probe (Fe), (NFe): 0.2mm 0.05mm
Minimum measuring area : 10x10mm
Minimum substrate thickness : 0.5mm
Power supply : 3×1.5V AA batteries
Out put : USB
Memory : 1200
Dimension of main unit : 88x67 x30mm
Weight of main unit : 120g
STANDARD DELIVERY : Main unit, Battery (AA), Zero calibration ,one point and two point calibration,USB Cable
OPTIONAL ACCESSORY Printer ISH-DS-PRINTER
