Magnification: 40X~600X
Eyepiece: 10X (view field: ϕ 20mm)
Infinite strain free plan achromatic objective: 4X(transmitted/reflected); 10X (transmitted/reflected); 20X (transmitted); 40X (transmitted); 60X (transmitted)
Working distance: 22.2mm; 6.1mm; 6.4mm; 0.6mm; 0.3mm
Numerical aperture: 0.1; 0.25; 0.4; 0.65; 0.8
Stage:
- Revolving round stage
- Diameter: ϕ160mm
- Graduation: 1 °
- Resolution: 6’
Pupil distance: 63~75mm
Diopter adjustment: ±5 diopter (one eyepiece)
Illumination:
- 12V/50W halogen lamp, brightness is adjustable (reflected illumination)
- 12V/50W halogen lamp, brightness is adjustable (transmitted illumination)
Power supply: 110/220V, 50/60Hz
Dimension: 614x250x394mm
Weight: 13kg
Standard delivery:
- Main unit: 1pc
- Micrometer: 1pc
- Grid plate: 1pc
- 10X crossing eyepiece (view field: ϕ20mm)
- 10X dividing eyepiece (view field: ϕ20mm, graduation: 0.1mm)
- λslip (first class red) and 1/4 λ slip
- Quartz wedge
Optional accessory:
- Objective for reflected system
- Objective for transmitted system
- Specimen presser
