Hardness scale:
- With standard indenters: RH15N, RH30N, RH45N, RH15T, RH30T, RH45T
- With optional indenters: RH15W, RH30W, RH45W, RH15X, RH30Y, RH45Y
Preliminary test force: 29.4N (3kgf)
Total test force: 147.1N (15kg); 294.2N(30kg); 441.3N(45kg)
Stage elevation: manual
Load control: automatic loading (load/dwell/unload)
Load dwell time: 0~60 sec
Resolution: 0.1HR
Output: USB
Max. workpiece height: 220mm
Max. workpiece depth: 200mm (from the center of indenter )
Power supply: 110/220V, 50/60Hz
Dimension: 510x260x780mm
Weight: 70kg
Standard delivery:
- Main unit: 1pc
- Φ63mm flat anvil: 1pc
- Φ150mm flat anvil: 1pc
- V-type anvil: 1pc
- Diamond indenter: 1pc
- Φ1.5875mm carbide ball indenter: 1pc
- Hardness test block HRB88~95: 1pc
- Hardness test block HRC20~30: 1pc
- Hardness test block HRC60~65: 1pc
- Hardness test block 78~88HR15N: _
- Hardness test block 55~73HR30N: _
- Hardness test block 57~69HR30T: _
- USB flash disk (8G): 1pc
- Level: 1pc
- Touch pen: 1pc
- Anti-dust cover: 1pc
Optional accessory:
- Hardness test block HRB88~95
- Hardness test block HRC20~30
- Hardness test block HRC60~65
- Hardness test block 78~88HR15N
- Hardness test block 55~73HR30N
- Hardness test block 57~69HR30T
- Small V type anvil
