Detector:
Analysis material: organic compounds, inorganic ions, biomolecules (such as DNA, proteins) with UV-visible absorption properties
Type: Ultraviolet-Visible detector
Wavelength range: 190~800nm
Baseline noise: ≤1.5×10⁵ AU
Baseline drift: ≤2.0×10⁻⁴ AU/h
Light source: deuterium lamp, tungsten lamp
Bandwidth: 8nm
Minimum detection concentration: ≤1.0×10⁻⁹ g/mL
Linear range: ≥2.5 AU
Wavelength accuracy: ±1nm
Wavelength repeatability: ≤±0.2nm
Detection cell temperature control: 5-55°C, setting step 0.1°C
Detection cell optical range: 10nm
Detection cell pressure: ≤0.1 MPa
High Pressure Pump:
Pump type: binary high pressure constant current pump
Gradient mixing accuracy: ±0.5%
Gradient mixing precision: ≤0.1%
Flow range: 0.001~10.000 mL/min
Maximum working pressure: 90 MPa
Flow stability: ≤0.06%
Gradient composition ratio: 0~100%, programmable range
Pressure pulsation: ≤0.1 MPa
Auto-sampler:
Temperature control range: 4~40°C
Special function: empty bottle detection and false tie alarm
Injection method: full loop injection, lossy injection, lossless injection
Input range: 0~100 μL
Vial quantity and specification: 210th (1mL vial), 120th (2mL vial), 72th (4mL vial), double 96-well plate (support base magnetic plate option)
Input residue: <0.002%
Sample repeatability: <0.03%
Feed rate: support high-speed sampling mode, the fastest can realize 1s sampling
Column Oven:
Temperature range:
- Heating mode: 10~85°C
- Cooling mode: 4~35°C
- Smart mode: 4~85°C
Power Supply: 110~220V, 50/60Hz, 1400W
Dimensions (LxWxH): 600×540×540mm
Weight: 75kg
STANDARD DELIVERY:
High pressure pump: 1 pc
Auto-sampler: 1 pc
Column oven: 1 pc
Ultraviolet-Visible detector: 1 pc
Solvent bottle tray: 1 pc
Sample cell: 1 pc
Chromatography data workstation: 1 set
Column (5 μm, 4.6×250 mm): 1 pc
Mobile phase solvent bottles: 2 pcs
Computer: 1 pc
Consumables and spare parts: 1 set*
*Including common consumable tools such as connecting pipes and pipe joints
