INSIZE HDT-ESD Digital shore durometers (0~100HD, shore D)

Unit:Shore D

Test material:high hardness vulcanized rubber and thermoplastic rubber, etc

Measuring range:0-100HD*

Resolution:0.2HD

Accuracy:±1HD

Indenter protrusion:2.5mm

Output:USB

Power supply:built-in rechargeable battery

Dimension:150×60×50mm

Weight:300g

* Use HDT-ESD when measuring result is higher than 90HA

Use HDT-ESA when measuring result is lower than 20HD

Standard Delivery:

Main unit:1pc

Software and USB cable:1pc

Power adapter:1pc

■ Meet the requirements of force measurement forward and reverse in the verification regulations

■ Digital displacement sensor, high test accuracy

■ Zero point calibration function, calibration block is not required

■ With average function, to have average values from 0 to 9 times

■ Can be used with test stand (optional) for high accuracy and stable measurement

■ According to ISO 48, ISO 7619, ISO 21509
