Test Force:
Brinell: 306.5N (31.25kg), 612.9N (62.5kg), 1226N (125kg), 1839N (187.5kg), 980.8N (100kg), 2451.6N (250kg)
Rockwell: 588N (60kg), 980N (100kg), 1471N (150kg)
Vickers: 49.03N (5kg), 98.07N (10kg), 196.1N (20kg), 294.2N (30kg), 490.3N (50kg), 980.7N (100kg)
Hardness Scale:
Brinell: HBW2.5/31.25, HBW2.5/62.5, HBW2.5/187.5, HBW5/62.5, HBW5/125, HBW5/250, HBW10/100, HBW10/250
Rockwell: HRA, HRB, HRC, HRD, HRF, HRG
Vickers: HV3, HV5, HV10, HV20, HV30, HV50, HV100
Conversion Scale: HRA, HRB, HRC, HRD, HRF, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HB, HV, HK
Range:
Brinell: 5-650HBW
Rockwell: 20-88HRA, 20-100HRB, 20-70HRC
Vickers: 10-2900HV
Stage Lifting: Manual
Load Control: Automatic (Load/Dwell/Unload)
Eyepiece: 10X
Objective:
2.5X (included, for Brinell)
5X (included, for Vickers)
10X (optional, for Vickers)
Resolution:
Brinell: 0.1HB
Rockwell: 0.1HR
Vickers: 0.1HV
Load Dwell Time: 0~99 seconds (adjustable)
Max. Testing Width: 160mm
Max. Workpiece Height:
Brinell: 165mm
Rockwell: 180mm
Vickers: 165mm
Power Supply: 220V, 50/60Hz
Dimension: 550×235×720mm
Weight: 80kg
STANDARD DELIVERY
Main Unit: 1 pc
Diamond Rockwell Indenter: 1 pc
Diamond Vickers Indenter: 1 pc
Ø2.5mm Ball Indenter: 1 pc
Ø5mm Ball Indenter: 1 pc
Ø1.5875 Carbide Ball Indenter: 1 pc
Ø150mm Flat Anvil: 1 pc
Ø60mm Flat Anvil: 1 pc
V-Type Anvil: 1 pc
Skateboard Stage: 1 pc
Internal Lighting Bulb: 1 pc
External Lighting Bulb: 1 pc
Hardness Test Block HRC20~30: 1 pc
Hardness Test Block HRC60~70: 1 pc
Hardness Test Block HRB85~100: 1 pc
Hardness Test Block HBW2.5/187.5: 1 pc
Hardness Test Block HV30: 1 pc
Anti-Dust Cover: 1 pc
