Range: (0-250)kPa/(0~2.5)bar
Connection: NPT1/2
Other ranges and connection can be customised according to customer requirements.
Accuracy: 0.05%FS
Overload pressure: 120%FS
Long-term stability: ±0.1%FS/year
Zero drift: ±0.1%FS
Dial diameter: 120mm
Pressure type: Gauge pressure
Unit: MPa, kPa, inHg, inH20, kgf/cm², mmH20, mmHg, mbar, bar, psi, Pa
Electrical connection: Measuring connection standard Ø4mm jack
Current measurement:
Range: (-30~30)mA
Resolution: 0.1μA
Accuracy: ±(0.01%RD+0.003%FS)
Voltage measurement:
Range: (-30~30)V
Resolution: 0.1μV
Accuracy: ±(0.01%RD+0.003%FS)
Pressure switch-off measurement: Voltage range 3V~24V (if with electric)
Temperature measurement:
Range: 0~50°C
Accuracy: ±1°C
24V DC output: 24V±0.5V, 50mA (max)
Operation environment:
Work temperature: 0~50°C
Humidity: (0~90%) RH (non-condensing)
Atmospheric pressure: 0.86~1.01bar/(86~101)kPa
Data interface: RS232
Power supply: Rechargeable lithium battery, power adapter-powered
Dimension: Header Ø120×45mm, overall length 190mm
Weight: 0.70kg
STANDARD DELIVERY:
Main unit: 1 pc
Power adapter: 1 pc
Current and voltage test line: 1 set
