Infrared image
Detector type: Unrefrigerated vanadium oxide, 7.5µm~14µm
Infrared resolution: 256×192@12µm
Thermal sensitivity / NETD: 45mK@30°C
Lens: 3.2mm, 56°×42°
Focusing mode: Focus-free
Color palettes: 26; white hot, black hot, rainbow, and so on
Featured function: Detail enhancement, 2D/3D noise reduction, image flip, dual light
Temperature measurement
Measurement range: Low: -20°C~150°C, High: 100°C~550°C
Measurement accuracy: ±2°C or ±2%, whichever is greater
Measurement target: Up to 21 targets (spot, line, rectangle, polygon, and circle) can be simultaneously measured
Measurement function: Cold/hot spot tracking, full-screen point temperature measuring, query and export of information
Visible light
Sensor type: 1/2.7" CMOS
Max. resolution: 1920×1080
Min. illuminance: Color: 0.005lux
Lens: 2.8mm, 65°×49°
Fill light: White light
Featured function: Visible light gain control, 2D/3D noise reduction, backlight compensation, wide dynamic, strong-light photoinhibition, image flip, exposure compensation
Interface
Power interface: DC12V±25%
Network interface: 100M/1000M Ethernet port, POE (802.3 at)
Alarm interface: 1 input and 1 output
Other interface: RS485
Environmental parameter
Operating environment: -30°C~60°C, ≤95%RH (non-condensing)
Protection: IP67, TVS 6000V lightning protection and surge protection
Physical parameter
Power: 3.5W
Dimension (L×W×H): 71×30×105mm
Weight: 300g
