Width: 4.5 mm
Height: 9.45 mm
Length: 10.2 mm
Fall Time: 9 nS
Rise Time: 11 ns
Technology: Si
Unit Weight: 2.387 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 63 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 151 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-Off Delay Time: 110 nS
Id - Continuous Drain Current: 20.2 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 190 mOhms
Vds - Drain-Source Breakdown Voltage: 650 V
Vgs th - Gate-Source Threshold Voltage: 3 V
