Number of stirring positions: 1
Stirring quantity max. per stirring position (H2O): 20 l
Motor rating output: 9 W
Direction of rotation: right
Speed display set-value: TFT
Speed display actual-value: TFT
Speed control: Turning knob
Speed range: 50 - 1700 rpm
Setting accuracy speed: 10 rpm
Stirring bar length: 20 - 80 mm
Self-heating of the set-up plate by max. stirring (RT:22°C/duration:1h): 28 +K
Heat output: 600 W
Temperature display set-value: TFT
Temperature display actual-value: TFT
Temperature unit: °C / °F
Heating temperature range: Room temp. + device self heating - 340 °C
Heat control: Turning knob
Temperature setting range: 0 - 340 °C
Temperature setting resolution of heating plate: 0.1 K
Connection for ext. temperature sensor: PT100/PT1000 (dual sensor)
Characteristics in the medium with temperature sensor: 1l M50 Oil at H1500
Temperature medium max.: 270 °C
Heating rate medium: 7 K/min
Temperature setting resolution of medium: 0.1 K
Adjustable safety circuit: 50 - 380 °C
Set-up plate material: stainless steel 1.4301
Set-up plate dimensions: Ø 135 mm
Intermittend mode: yes
Viscosity trend measurement: yes
Break detection stirring bar: yes
Timer: yes
pH measurement: yes
Graph function: yes
Programs: yes
Sensor in medium detection (Error 5): yes
Weighing function: yes
Weighing range: 10-5000 g
Weighing accuracy: ±(0.3%+2) g
Load capacity weighing function max.: 5 kg
Dimensions: (W x H x D) 160 x 85 x 270 mm
Weight: 2.7 kg
Permissible ambient temperature 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 42
RS 232 interface: yes
USB interface: yes
Voltage: 220 - 230 / 115 / 100 V
Frequency: 50/60 Hz
Power input: 650 W
