Number of stirring positions: 1
Stirring quantity max. per stirring position (H2O): 20 l
Motor rating output: 9 W
Direction of rotation: right / left
Speed display set-value: LCD
Speed display actual-value: LCD
Speed control: Turning knob
Speed range: 50 - 1500 rpm
Setting accuracy speed: 10 rpm
Stirring bar length: 30 - 80 mm
Self-heating of the set-up plate by max. stirring (RT:22°C/duration:1h): 13 +K
Heat output: 600 W
Temperature display set-value: LCD
Temperature display actual-value: LCD
Temperature unit: °C / °F
Heating temperature range: Room temp. + device self heating - 310 °C
Heat control: Turning knob
Temperature setting range: 0 - 310 °C
Temperature setting resolution of heating plate: 1 K
Connection for ext. temperature sensor: PT1000, ETS-D5, ETS-D6
Temperature setting resolution of medium: 1 K
Adjustable safety circuit: 50 - 370 °C
Set-up plate material: Aluminium alloy
Set-up plate dimensions: Ø 135 mm
Automatic reverse rotation: yes
Intermittend mode: yes
Viscosity trend measurement: yes
Timer: yes
Sensor in medium detection (Error 5): yes
Speed deviation (no load,nominal voltage, at 1500rpm + 25 °C): 2 ±%
Heating rate (1l H2O in H1500): 6.5 K/min
Heat control accuracy of heating plate (at 100°C): 5 ±K
Heat control accuracy with ext. PT1000 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C): 0.5 ±K
Heat control accuracy with ETS-D5 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C): 0.5 ±K
Heat control accuracy with ETS-D6 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C): 0.2 ±K
Dimensions: (W x H x D) 160 x 85 x 270 mm
Weight: 2.3 kg
Permissible ambient temperature 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 42
RS 232 interface: yes
USB interface: yes
Voltage: 220 - 230 / 115 / 100 V
Frequency: 50/60 Hz
Power input: 650 W
Power input standby: 1.6 W
