Voltage: 150V
Current: 4200A
Power: 21000W
Min. Operating Voltage: 0.7V
CV Mode:
Range: 0~15V/ 0~75V/ 0~150V
Setting Resolution: 1mV/ 1mV/ 10mV
Setting Accuracy (23±5℃): 0.05%+0.05%F.S.
Readback Accuracy(23±5℃): 0.05%+0.05%F.S.
CC Mode:
Range: 0~42A/ 0~420A/ 0~4200A
Setting Resolution: 0.1mA/ 1mA/ 10mA
Setting Accuracy (23±5℃): 0.1%+1%F.S./ 0.1%+0.1%F.S.
Readback Resolution: 10μA/ 0.1mA/ 1mA
Readback Accuracy(23±5℃): 0.1%+1%F.S./ 0.1%+0.1%F.S.
CP Mode:
Range: 0~210W/ 0~2100W/ 0~21000W
Setting Accuracy (23±5℃): 0.2%+0.2%F.S.
Readback Accuracy(23±5℃): 0.1%+0.1%F.S.
CCD Mode:
T1&T2: 0.005~60000ms
Resolution: 1μs
Accuracy (23±5℃): 10μs+100ppm
Min. Rise Time: 6μs
Others:
Input Impedance: 0.21MΩ(Typical)
Protection Function: OVP/OCP/OPP/OTP/RV
Interface: USB(Waveform import)/LAN/RS232/CAN
Communication Protocol: Modbus-RTU standard protocol, CANOPEN standard protocol, SCPI standard protocol
Communication Response Time: ≤5ms
AC Input: AC 100V~240V, current ＜ 0.5A, frequency 47Hz~63Hz
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Dimension: 88.0(H)*482.0(W)with handle*664.5(D)mm
