Voltage: 60V/CH
Current: 10A/CH
Power: 200W/CH
Channels: 2CH
CV Mode:
Range: 0~60V
Setting Resolution: 1mV
Setting Accuracy (23±5°C): 0.05%+0.1%F.S.
Setting Temperature Coefficient (0~40°C): 50ppm /°C
Readback Resolution: 1mV
Readback Accuracy (23±5°C): 0.05%+0.1%F.S.
Readback Temperature Coefficient ( 0~40°C): 50ppm /°C
CC Mode:
Range: 0~10A
Setting Resolution: 1mA
Setting Accuracy(23±5°C): 0.1%+0.1%F.S.
Readback Resolution: 1mA
Readback Accuracy(23±5°C): 0.1%+0.1%F.S.
Temperature Coefficient (0~40°C): 50ppm/°C
Output Noise & Ripple(20Hz-20MHz):
Voltage Ripple: 100mVp-p; 10mVrms
Line Regulation: ≤0.015%(Voltage)
Load Regulation: ≤0.03%(Voltage)
Voltage Rise Time (no load): ≤50ms
Voltage Fall Time (no load): ≤50ms
Others:
Interface: LAN/RS232
AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz
Temperature: Operating temperature: 0°C~40°C, storage temperature: -20°C~60°C
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 7kg
Dimension: 2U, 88.0(H)*214.0(W)*546.0(D)mm
