Voltage: 0~1000V
Current : -80A~+80A
Power: -32kW~+32kW
CV Mode:
Range: 0~1000V
Setting Resolution: 10mV
Setting Accuracy(23±5°C): ≤0.02%+0.02%F.S.
Voltage Ripple(20Hz-20MHz) : ≤2Vp-p; ≤400mVrms
CC Mode:
Range: -80A~+80A
Setting Resolution: 0.1mA
Setting Accuracy(23±5°C): ≤0.1%+0.1%F.S
Current Ripple(20Hz-20MHz): ≤1.4Ap-p; ≤200mArms
CP Mode:
Range: -32kW~+32kW
Setting Resolution: 0.1W
Setting Accuracy(23±5°C): ≤0.1%+0.1%F.S.
Voltage Measurement:
Range: 0~1000V
Readback Resolution: 10mV
Readback Accuracy(23±5°C): ≤0.02%+0.02%F.S
Temperature Coefficient: ≤15ppm/°C
Current Measurement:
Range: -80A~+80A
Readback Resolution: 0.1mA
Readback Accuracy(23±5°C): ≤0.1%+0.1%F.S.
Temperature Coefficient: ≤30ppm/°C
Dynamic Characteristics:
Voltage Rise Time (no load 10%~90%) : ≤5ms
Voltage Rise Time (full load 10%~90%) : ≤5ms
Voltage Fall Time (no load 90%~10%) 1: ≤10ms
Voltage Fall Time (full load 90%~10%): ≤5ms
Transient Response Time: The recovery time of load varying from 10% to 60% and output voltage recovering within 0.75% of rated voltage is less than 1ms.
Line Regulation:
Voltage: <0.01%F.S.
Current: <0.02%F.S.
Load Regulation:
Voltage: <0.01%F.S.
Current: <0.05%F.S.
Others:
Isolation (Output to ground): 1500V DC
Max. Efficiency: 93%
Power Factor: 0.99
Protection: OVP/OCP/OPP/UVP/UCP
Interface: LAN/RS232/RS485/CAN
Communication Response Time: 5ms
Temperature: Operating temperature: 0°C~50°C (>35°C derating output); Storage temperature: -10°C~70°C
Operating Environment: Altitude <2000m; relative humidity:5%~90%RH(non-condensing); atmospheric pressure: 80~110kPa
