1.Rated Operating Conditions:
Operating Voltage: AC220V±10% 50Hz
Operating Conditions: Temp0~40℃ Relative Humidity: ≤80%RH
Storage Conditions: Temp-20~60℃ Relative Humidity: ≤80%RH
Temperature Range for Guaranteed Accuracy: 23℃±5℃
2.Technical Specifications
Max. Voltage: 60V
Max. Current: 5A
Voltage:
Setting Resolution: <100V: 10mV; ≥100V: 0.1V
Setting Accuracy: ≤0.1%+5digits
Readback Resolution: <100V: 10mV; ≥100V: 0.1V
Readback Accuracy: ≤0.1%+5digits
Temp. Coefficient: ≤0.02%+3mV
Ripple: ≤15mVrms
Current:
Setting Resolution: <10A: 1mA; ≥10A: 10mA
Setting Accuracy: ≤0.2%+10digits
Readback Resolution: <10A: 1mA; ≥10A: 10mA
Readback Accuracy: ≤0.2%+10digits
Temp. Coefficient: ≤0.02%+3mA
Ripple: ≤15mArms
Load Regulation: <10A: ≤0.1%Umax+5mV; ≥10A: ≤0.2%Umax+5mV
Line Regulation: <10A: ≤0.1%Umax+5mV; ≥10A: ≤0.2%Umax+5mV
OVP: 0-65V
OCP: 0-5.5A
Power Input: AC 220V±10%, 50Hz (Optional: Fixed AC110V input; or AC110V/220V switchable input)
Accessories: Power cord x1, 5A clip lead x1, Manual x1, Certificate x1
Cooling Method: Air Cooled
Weight: ≤2.2KG
Unit Dimensions (LxWxH): 280(D)×130(W)×165(H)mm
Package Dimensions (LxWxH): 355(D)×178(W)×210(H)mm
Note: Please ensure warm-up time over 10 minutes when using these specifications.
