Light type: Red light
Operating voltage [V]: 10...36 DC
Current consumption [mA]: 25
Protection class: II
Reverse polarity protection: Yes
Wave length [nm]: 660
Electrical design: PNP
Output function: Light/Dark mode; (programmable)
Max. voltage drop switching output DC [V]: 2.5
Permanent current rating of switching output DC [mA]: 200
Switching frequency DC [Hz]: 1000
Permanent current rating of switching output DC [mA]: 200
Short-circuit protection: Yes
Short-circuit protection type: Pulsed
Overload protection: Yes
Sensing range [mm]: 15...400; (white paper 200 x 200 mm 90% remission)
Range adjustment: Yes
Maximum light spot diameter [mm]: 18
Reference light spot size: Range
Background suppression available: Yes
Ambient temperature [°C]: -25...60
Degree of protection: IP67
Weight [g]: 34.9
Dimensions [mm]: 35 x 11 x 24
Material: Housing: ABS; LED window: SEPS; Pushbutton: SEPS
Lens material: PMMA
Lens alignment: Lateral lens
Display: Switching status 1 x LED, yellow | Operation 1 x LED, green
Electronic lock: Yes
Connection: Connector: 1 x M12; Coding: A
