Type of light: red light
Operating voltage [V]: 10...30 DC; (supply class 2 to cULus)
Rated insulation voltage [V]: 32
Current consumption [mA]: 17
Protection class: III
Reverse polarity protection: yes
Max. power-on delay time [ms]: 300
Wave length [nm]: 662
Transmitter / receiver: transmitter
Range [m]: 20
Max. light spot diameter [mm]: 800
Communication interface: IO-Link
Transmission type: COM2 (38,4 kBaud)
IO-Link revision: 1.1
SIO mode: no
Required master port type: A
Min. process cycle time [ms]: 2.5
Communication interface: IO-Link
Transmission type: COM3 (230,4 kBaud)
IO-Link process data (cyclical): function: bit length; device status: 4
IO-Link functions (acyclical): application specific tag; operating hours counter
Ambient temperature [°C]: -25...60
Storage temperature [°C]: -40...60
Protection: IP 65; IP 67
Weight [g]: 59.5
Dimensions [mm]: 52.6 x 19 x 36
Thread designation: M18 x 1
Lens alignment: side lens
Display: operation 1 x LED, green
