Light type: Red light
Operating voltage [V]: 10...36 DC
Current consumption [mA]: 25
Protection class: II
Reverse polarity protection: Yes
Wave length [nm]: 624
Electrical design: PNP
Output function: Light/dark mode; (programmable)
Max. voltage drop switching output DC [V]: 2.5
Permanent current rating of switching output DC [mA]: 150; (200 (...60 °C))
Switching frequency DC [Hz]: 1000
Default setting: Light-on mode
Short-circuit protection: Yes
Short-circuit protection type: Pulsed
Overload protection: Yes
Sensing range [mm]: 15...300; (white paper 200 x 200 mm, 90% remission)
Range on white object (90% remission) [mm]: 15...300
Range on grey object (18% remission) [mm]: 15...290
Range on black object (6% remission) [mm]: 15...190
Adjustable range: Yes
Max. light spot diameter [mm]: 25
Reference light spot size: At maximum range
Background suppression available: Yes
Ambient temperature [°C]: -25...80
Degree of protection: IP65
Weight [g]: 61.1
Dimensions [mm]: M18 x 1 / L = 72
Display: Switching status 1 x LED, yellow
Item supplied: Lock nuts: 2 x
Connection: Connector: 1 x M12; coding: A
