Type of light: red light
Housing: rectangular
Function principle: Through-beam sensor
Operating voltage [V]: 10...36 DC
Current consumption [mA]: 11
Protection class: II
Reverse polarity protection: yes
Wave length [nm]: 655
Electrical design: PNP
Output function: light-on/dark-on mode; (programmable)
Max. voltage drop switching output DC [V]: 2.5
Permanent current rating of switching output DC [mA]: 200
Switching frequency DC [Hz]: 1000
Short-circuit protection: yes
Type of short-circuit protection: pulsed
Transmitter / receiver: receiver
Range [m]: < 60
Range adjustable: yes
Diameter of the smallest detectable object [mm]: 3; (60 m)
Ambient temperature [°C]: -10...60
Protection: IP 65; IP 67
Weight [g]: 61.9
Dimensions [mm]: M18 x 1 / L = 72
Materials: stainless steel (1.4404 / 316L); PA; LCP; EPDM; TPU
Lens material: PMMA
Display: switching status 1 x LED, yellow
Items supplied: lock nuts: 2 x
Connection: Connector: 1 x M12; coding: A
