Type of light: red light
Housing: threaded type
Function principle: Through-beam sensor
Operating voltage [V]: 10...36 DC
Current consumption [mA]: 11
Protection class: III
Reverse polarity protection: yes
Wave length [nm]: 624
Electrical design: PNP
Output function: light-on/dark-on mode; (programmable)
Max. voltage drop switching output DC [V]: 2.5
Permanent current rating of switching output DC [mA]: 150; (200 (...60 °C))
Switching frequency DC [Hz]: 1000
Short-circuit protection: yes
Type of short-circuit protection: pulsed
Overload protection: yes
Transmitter / receiver: receiver
Range [m]: < 25
Factory setting: dark-on mode
Range adjustable: yes
Ambient temperature [°C]: -25...80
Protection: IP 67
Weight [g]:: 50
Dimensions [mm]:: M18 x 1 / L = 72
Thread designation: M18 x 1
Materials: stainless steel (1.4404 / 316L); PA; LCP; EPDM; TPU
Lens material: PMMA
Lens alignment: side lens
Display: switching status 1 x LED, yellow
