Type of light: red light
Operating voltage [V]: 10...30 DC
Current consumption [mA]: 16
Protection class: III
Reverse polarity protection: yes
Wave length [nm]: 662
Electrical design: PNP
Output function: light-on mode
Max. voltage drop switching output DC [V]: 2.5
Permanent current rating of switching output DC [mA]: 200
Switching frequency DC [Hz]: 1000
Short-circuit protection: yes
Type of short-circuit protection: pulsed
Transmitter / receiver: receiver
Range [m]: < 15
Range adjustable: no
Communication interface: IO-Link
Transmission type: COM2 (38.4 kBaud)
IO-Link revision: 1.1
SIO mode: yes
Required master port type: A
Min. process cycle time [ms]: 2.5
IO-Link process data (cyclical): function: bit length; device status: 4; binary switching information: 1
IO-Link functions (acyclical): application specific tag; operating hours counter
Ambient temperature [°C]: -25...80
Storage temperature [°C]: -40...80
Protection: IP 65; IP 67; IP 68; IP 69K
Weight [g]: 78
Dimensions [mm]: 52.9 x 20 x 34.6
Lens alignment: side lens
Display: operation 1 x LED, green
